Auto Glazing Desiccant Filling Machine / Automatic Aluminum Desiccant Filling Machine

Name: Auto Glazing Desiccant Filling Machine Automatic Aluminum Desiccant Filling Machine
Brand: LIJIANG
Price: 1 USD

Auto Glazing Desiccant Filling Machine / Automatic Aluminum Desiccant Filling Machine Manufactures

Brand Name : LIJIANG

Model Number : LJTJ2540

Certification : CE ISO

Place of Origin : CHINA

MOQ : Negotiable

Price : Negotiation

Production name : Automatic desiccant filling machine

barrel : big barrel

After-sales Service Provided : Engineers available to service machinery overseas

Filling aluminum frame's maximum size : 2000mm*2000mm

Filling aluminum frame's minimal size : 300mm*250mm

Molecular sieve diameter needed : 0.5- 0.9 mm

Contact Now

auto glazing desiccant filling machine for double glass sale/Automatic aluminum desiccant filling machine

Main features:
1. The filling height of head can be adjusted according to the size of spacer frame.
2. Filling time can be adjusted.
3. Desiccant auto loading and replenish.
4. Auto drilling, filling and sealing function.
5. Germany Siemens PLC control system.
6. Touching screen interface, simple and visible.
7. Can fill arc Arc-shaped aluminum frame (New function)

Technical data
Filling aluminum frame’s maximum size	2500mm*2500mm
Filling aluminum frame’s minimal size	300mm*250mm
Aluminum specifications	5.5-24mm
Air source	≥0.65MPa
Power supply and power consumption	AC220V 50Hz 1KW
Molecular sieve diameter needed	0.5-0.9mm
Dimension	1300mm1100mm3650mm

1.Protection device for machine head.
